Impex Tube India is a renowned Mumbai-based manufacturer and supplier of high-quality pipes and tubes in India that provide world–class Marine Grade Stainless Steel Pipes. Renowned for their robustness and capability to withstand corrosive marine conditions, these pipes are designed with superior quality as a prime objective. Impex Tube India adopts modern manufacturing technologies and rigorous quality controls to produce products that are able to outshine in terms of performance. Supplying industries like shipbuilding, offshore platforms, and coastal construction, the company has established a strong reputation for providing dependable, corrosion-resistant products specifically designed to resist aggressive saltwater conditions.
Marine Grade Stainless Steel Pipes are usually fabricated using alloys like Stainless Steel 316 or 316L, containing approximately 16–18% chromium, 10–14% nickel, and 2–3% molybdenum. This content improves their pitting, crevice corrosion, and chloride attack resistance in marine conditions. These pipes have very good mechanical properties, with tensile strength of about 515 MPa, yield strength of around 205 MPa, and satisfactory elongation. They are non-magnetic and can be welded, with high toughness even under sub-zero conditions, making them suitable for challenging sea and industrial environments.
| Size | 1/8″(10.3mm) to 12″(323.8mm) |
| Grades | TP -304, 316,316L, |
| Schedule | 5/5S,10/10S,20/20S,40/40S,80/80S,120/120S,160/160S according to ANSI B36.19/36.10 |
| Marine Grade Stainless Steel Pipe Applications | marine fittings, marine fasteners, and marine structures |
| Finish | Satin Finish(180#.240#.320#).,Bright Finish(400#,600#,mirror),Mill Finish(2B),Hairline-Finish(HL/Brushed),Ti-gold, Glossy matt,dull and so on. |
| PIPE SIZE | OD IN INCHES | A.S.A. Pipe Schedules | |||||||||||||||
| 5s | 5 | 10s | 10 | 20 | 30 | 40s & Std. | 40 | 60 | 80s & E.H. | 80 | 100 | 120 | 140 | 160 | DBL E.H. | ||
| 1/8 | .405 | .035.1383 | .049.1863 | .049.1863 | .068.2447 | 068.2447 | 0.95.3145 | 0.95.3145 | |||||||||
| 1/4 | .540 | .049.2570 | .065.3297 | .065.3297 | .088.4248 | 088.4248 | .119.5351 | .119.5351 | |||||||||
| 3/8 | .675 | .049.3276 | .065.4235 | .065.4235 | .091.5676 | .091.5676 | .126.7338 | .126.7338 | |||||||||
| 1/2 | .840 | .065.5383 | .065.5383 | .083.6710 | .083.6710 | .109.8510 | .109.8510 | .1471.088 | .1471.088 | .1871.304 | .2941.714 | ||||||
| 3/4 | 1.050 | .065.6838 | .065.6838 | .083.8572 | .083.8572 | .1131.131 | .1131.131 | .1541.474 | .1541.474 | .2181.937 | .3082.441 | ||||||
| 1 | 1.315 | .065.8678 | .065.8678 | .1091.404 | .1091.404 | .1331.679 | .1331.679 | .1792.172 | .1792.172 | .2502.844 | .3583.659 | ||||||
| 1-1/4 | 1.660 | .0651.107 | .0651.107 | .1091.806 | .1091.806 | .1402.273 | .1402.273 | .1912.997 | .1912.997 | .2503.765 | .3825.214 | ||||||
| 1-1/2 | 1.900 | .0651.274 | .0651.274 | .1092.085 | .1092.085 | .1452.718 | .1452.718 | .2003.631 | .2003.631 | .2814.859 | .4006.408 | ||||||
| 2 | 2.375 | .0651.604 | .0651.604 | .1092.638 | .1092.638 | .1543.653 | .1543.653 | .2185.022 | .2185.022 | .3437.444 | .4369.029 | ||||||
| 2-1/2 | 2.875 | .0832.475 | .0832.475 | .1203.531 | .1203.531 | .2035.793 | .2035.793 | .2767.661 | .2767.661 | .37510.01 | .55213.70 | ||||||
| 3 | 3.500 | .0833.029 | .0833.029 | .1204.332 | .1204.332 | .2167.576 | .2167.576 | .30010.25 | .30010.25 | .43714.32 | .60018.58 | ||||||
| 3-1/2 | 4.000 | .0833.472 | .0833.472 | .1204.973 | .1204.973 | .2269.109 | .2269.109 | .31812.51 | .31812.51 | .63622.85 | |||||||
| 4 | 4.500 | .0833.915 | .0833.915 | .1205.613 | .1205.613 | .23710.79 | .23710.79 | .28112.66 | .33714.98 | .33714.98 | .43719.01 | .53122.51 | .67427.54 | ||||
| 4-1/2 | 5.000 | .24712.53 | .35517.61 | .71032.53 | |||||||||||||
| 5 | 5.563 | .1096.349 | .1096.349 | .1347.770 | .1347.770 | .25814.62 | .25814.62 | .37520.78 | .37520.78 | .50027.04 | .62532.96 | .75038.55 | |||||
| 6 | 6.625 | .1097.585 | .1097.585 | .1349.290 | .1349.290 | .28018.97 | .28018.97 | .43228.57 | .43228.57 | .56236.39 | .71845.30 | .86453.16 | |||||
| 7 | 7.625 | .30123.57 | .50038.05 | .87563.08 | |||||||||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Marine Grade Stainless Steel Pipes from Impex Tube India ensures high-quality materials with excellent corrosion resistance and durability. Our products are tailored to meet diverse industry standards, offering reliability and versatility for various applications. Our commitment to customer service and timely delivery makes us a trusted supplier.
Impex Tube India, one of the largest suppliers of Marine Grade Stainless Steel Pipes in Mumbai, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
| Marine Grade Stainless Steel Pipe Grades | UNS | Si | Mn | S | C | P | Cr | Ni | Mo |
|---|---|---|---|---|---|---|---|---|---|
| TP304 | S30400 | 1 | 2 | 0.03 | 0.08 | 0.045 | 18.0-20.0 | 8.0-11.0 | – |
| TP304L | S30403 | 1 | 2 | 0.03 | 0.035 | 0.045 | 18.0-20.0 | 8.0-13.0 | – |
| Material | Tensile Strength | Yield Strength | Heat | Temperure | Elongation %, Min |
|---|---|---|---|---|---|
| Ksi (MPa), Min. | Ksi (MPa), Min. | Treatment | Min. | ||
| º F(º C) | |||||
| Stainless Steel | 75(515) | 30(205) | Solution | 1900 (1040) | 35 |
| Nominal | SS Square Pipe Schedule 5 | SS Square Pipe Schedule 10 | SS Square Pipe Schedule 40 | |||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Inch | MM | Wt./MM | Kg./M | Kg./Ft | Wt./MM | Kg./M | Kg./Ft | Wt./MM | Kg./M | Kg./Ft |
| 1 / 2 | 21 | 1.65 | 0.801 | 0.244 | 2.11 | 0.999 | 0.305 | 2.77 | 1.270 | 0.387 |
| 3 / 4 | 21.30 | 1.65 | 1.020 | 0.311 | 2.11 | 1.280 | 0.390 | 2.87 | 1.680 | 0.512 |
| 1 | 26.70 | 1.65 | 1.290 | 0.393 | 2.77 | 2.090 | 0.637 | 3.38 | 2.500 | 0.762 |
| 1 1 / 4 | 33.40 | 1.65 | 1.650 | 0.503 | 2.77 | 2.690 | 0.820 | 3.56 | 3.380 | 1.030 |
| 1 1 / 2 | 42.20 | 1.65 | 1.900 | 0.579 | 2.77 | 3.110 | 0.948 | 3.68 | 4.050 | 1.230 |
| 2 | 48.30 | 1.65 | 3.340 | 0.728 | 2.77 | 3.920 | 1.200 | – | – | – |
| 2 1 / 2 | 73.00 | 2.11 | 3.690 | 1.130 | 3.05 | 5.260 | 1.600 | – | – | – |
| 3 | 88.90 | 2.11 | 4.510 | 1.380 | 3.05 | 6.450 | 1.970 | – | – | – |
| 3 1 / 2 | 101.60 | 2.11 | 5.190 | 1.580 | 3.05 | 7.400 | 2.260 | – | – | – |
Yes, we offer custom sizes for Marine Grade Stainless Steel Pipes to meet your specific requirements. Our team at Impex Tube India is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@impextubeind.com.
Marine Grade Stainless Steel Pipes are widely used in offshore and coastal industries because they have excellent resistance to seawater corrosion and long durability. They are commonly used in ship construction, desalination plants, marine hardware, offshore oil rigs, and oil platforms, where exposure to seawater and extreme environmental conditions is prevalent. They are also applied in port facilities, underwater pipelines, and power generation plants. Their extreme durability, low maintenance, and capacity to work under extreme pressure and temperature make them a best fit to provide security and longevity in vital marine and industrial use.
