Incoloy Pipe is a nickel-iron-chromium alloy, usually alloyed with other elements like molybdenum, copper, and titanium to improve corrosion resistance and mechanical properties. Its common composition has 30–46% nickel, 19–23% chromium, and iron, molybdenum, and copper in varying percentages depending on grade (e.g., Incoloy 800, 825). Pipes made from these materials exhibit excellent oxidation, carburization, and acidic environment resistance. In terms of mechanics, they possess tensile strength from 500 to 700 MPa, yield strength at approximately 200–300 MPa, and good ductility. Incoloy Pipes have structural integrity over a broad range of temperatures and are, therefore, suitable for severe, high-temperature applications.
| Alloy 800 Pipe Specification | ASTM B 167 ASME SB 167 / ASTM B 829 ASME SB 829 / ASTM B 517 ASME SB 517 |
|---|---|
| Incoloy Alloy 800 Pipe Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Our Presence | USA, Canada, Australia, India, Malaysia, Poland, Iran, Italy, Singapore, India |
| Incoloy 800 Welded Pipe size | 5.0 mm – 1219.2 mm |
| Alloy 800 EFW Pipe size | 5.0 mm – 1219.2 mm |
| Specialized in | Large Diameter Alloy 800 Pipe |
| Incoloy 800 Pipe Form | Hollow, Square, Round, Rectangular , Straight Pipes, Hydraulic Etc. |
| Alloy 800 Pipe End | Plain End, Beveled End, Treaded. |
| Incoloy 800 Pipe Length | Single Random, Double Random & Cut Length. |
| Alloy 800 Seamless Pipe size | 4 to 219mm W. T.: 0.5 to 20mm |
| Marking | All Incoloy Alloy 800 Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Manufacturers of Incoloy 800 Pipe |
|
| Incoloy 800 Pipe Schedule | SCH5, SCH10, SCH40, STD, SCH80, SCH160 |
| Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2 |
| Test |
|
| Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| Grade | C | Mn | Si | Fe | S | Cr | Al-Ti | Ni | |
| Incoloy 800 Pipe | min. | – | – | – | 39.5 | – | 19.0 | 0.15 | 30.0 |
| max. | 0.1 | 1.5 | 1.0 | – | 0.015 | 23.0 | 0.60 | 35.0 | |
| Incoloy 800H Pipe | min. | 0.05 | – | – | 39.5 | – | 19.0 | 0.15 | 30.0 |
| max. | 0.1 | 1.5 | 1.0 | – | 0.015 | 23.0 | 0.60 | 35.0 | |
| Incoloy 800HT Pipe | min. | 0.06 | – | – | 39.5 | – | 19.0 | 0.85/0.25 | 30.0 |
| max. | 0.1 | 1.5 | 1.0 | – | 0.015 | 23.0 | 1.20/0.60 | 35.0 | |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 800-H-HT | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa –205 | 30 | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Incoloy Pipe from Impex Tube India ensures superior corrosion resistance, excellent thermal conductivity, high strength, and long-lasting performance. Our commitment to quality and precision makes our pipes and tubing ideal for demanding industrial applications.
Impex Tube India is the largest supplier of Incoloy Pipe in Mumbai, India. We offer premium-quality, corrosion-resistant pipes and tubing ideal for marine, chemical, and industrial applications, with our reliable delivery and customized solutions to meet diverse client needs.
Yes, custom sizes are available for Incoloy Pipe to meet specific requirements. These pipes can be tailored for various industrial applications. For more details, contact us at sales@impextubeind.com.
Incoloy Pipe is commonly used across industries that necessitate excellent corrosion and heat resistance. Within the chemical and petrochemical industries, it is utilized for process piping, heat exchangers, and reactor vessels because of its resistance to acid and high-temperature environments. The oil and gas sector employs it in offshore platforms, risers, and sour gas systems. Power plants depend on it for superheaters, reheaters, and steam generator tubing. Incoloy Pipes are also critical in marine engineering, pollution control systems, and nuclear use. Their excellent weldability, thermal fatigue resistance, and high strength make them ideal for demanding and intricate engineering projects.
