Home > Stainless Steel >Stainless Steel 304H EFW pipes
Impex Tube India is a leading manufacturer and Mumbai-based supplier of high-quality Stainless Steel 304H EFW Pipes. Impex Tube India produces these pipes with precision and makes them highly sought after by industries like chemical, petrochemical, and power generation. Due to their superior strength, durability, and high-temperature resistance, Stainless Steel 304H EFW Pipes from Impex Tube India deliver superior performance in high-stress applications. The company prioritizes quality, offering top-notch products to meet diverse customer needs.
Stainless Steel 304H EFW Pipes consist mainly of iron, chromium (18-20%), nickel (8-12%), and a trace amount of carbon (0.04-0.10%). This makes its strength and resistance to corrosion greater. The mechanical characteristics are tensile strength (520 MPa), yield strength (205 MPa), and high elongation (40%), providing durability for extreme temperatures. The pipes are very resistant to oxidation and corrosion, particularly in high-temperature applications. The benefits of Stainless Steel 304H EFW Pipes are high strength, good weldability, resistance to scaling and dependability under harsh conditions, hence suitable for industrial use.
| Specification | ASTM A358 / ASME SA358 |
| Specification | A / SA358 CLASS 1, A / SA358 CLASS 2, A / SA358 CLASS 3, A / SA358 CLASS 4, A / SA358 CLASS 5 |
| Grades | 304, 304L, 304H, 309S, 310S, 316, 316L, 316H, 317L, 321, 321H, 347, 347H, 904L ETC. |
| Type | EFW, ELECTRIC FUSION WELDED |
| Outer Diameter Size | Electric Fusion Welded / ERW- 8″ NB To 110″ NB (Nominal Bore Size) |
| Wall Thickness | Schedule 10 To Schedule 160 (3 mm to 100 mm Thickness) |
| Length | 01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size. |
| Ends | Plain Ends / Beveled Ends |
| Delivery Conditions | As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered |
| Coating | Electropolish, Mechanical Polish, Satin Finish, Passivated |
| Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME |
| Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
| Packaging | Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 304H | S30409 | 1.4948 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304H | 0.10 max | 2.0 max | 0.75 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 10.5 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| SS 304H | 515 | 205 | 40 | 92 | 201 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Selecting Stainless Steel 304H EFW Pipes from Impex Tube India ensures superior corrosion resistance, high strength, and durability. Engineered for various industrial uses, it provides consistent performance in harsh environments while offering competitive pricing for cost-effective solutions.
Impex Tube India, a renowned Stainless Steel 304H EFW Pipes manufacturer and supplier in Mumbai, India, provides an extensive variety of high-quality pipes and tubing for industrial applications.
| NPS Designator | Outside Diameter | Nominal Wall Thickness | ||||||||
| in. | mm | Schedule 5SA | Schedule 10SA | Schedule 40SA | Schedule 80SA | |||||
| in. | mm | in. | mm | in. | mm | in. | mm | |||
| 8 | 8.625 | 219.08 | 0.109 | 2.77 | 0.148 | 3.76 | 0.322 | 8.18 | 0.500 | 12.70 |
| 10 | 10.750 | 273.05 | 0.134 | 3.40 | 0.165 | 4.19 | 0.365 | 9.27 | 0.500B | 12.70B |
| 12 | 12.750 | 323.85 | 0.156 | 3.96 | 0.180 | 4.57 | 0.375B | 9.52B | 0.500B | 12.70B |
| 14 | 14.000 | 355.60 | 0.156 | 3.96 | 0.188B | 4.78B | … | … | … | … |
| 16 | 16.000 | 406.40 | 0.165 | 4.19 | 0.188B | 4.78B | … | … | … | … |
| 18 | 18.000 | 457.20 | 0.165 | 4.19 | 0.188B | 4.78B | … | … | … | … |
| 20 | 20.000 | 508.00 | 0.188 | 4.78 | 0.188B | 4.78B | … | … | … | … |
| 22 | 22.000 | 558.80 | 0.188 | 4.78 | 0.218B | 5.54B | … | … | … | … |
| 24 | 24.000 | 609.60 | 0.218 | 5.54 | 0.250 | 6.35 | … | … | … | … |
| 30 | 30.000 | 762.00 | 0.250 | 6.35 | 0.312 | 7.92 | … | … | … | … |
| Grade | Density (kg/m3) | Specific Heat 0-1000C (J/kg.K) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Electrical Resistivity (n.m) | |||
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 304H | 8000 | 500 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 720 |
We provide bespoke sizes for Stainless Steel 304H EFW Pipes according to your requirement. Our committed team at Impex Tube India offers customized solutions for all your piping and tubing needs. For more information, contact us at sales@www.impextubeind.com.
Stainless Steel 304H EFW Pipes find extensive applications in high-temperature applications because of their superior strength and resistance to oxidation. They are commonly applied in power generation plants, chemical processing, petrochemical plants, and heat exchangers. They are also used in boilers, furnace parts, and reactors where there is a need for high heat and corrosion resistance. Moreover, these pipes are suitable for the production of components that need to withstand harsh conditions, including pressure vessels and steam lines. They are versatile and reliable and are used in many demanding industrial applications.
