Home > Stainless Steel >Stainless Steel 304 EFW pipes
Impex Tube India, a manufacturer and supplier company based in Mumbai, India, is known for producing high-quality stainless steel products with specialization in Stainless Steel 304 EFW (Electric Fusion Welded) pipes. They are a renowned company with a strong faith in excellence. They provide robust and reliable solutions to various industries. Their Stainless Steel 304 EFW pipes are known for having high corrosion resistance, toughness, and long-lasting performance. Impex Tube India provides customer satisfaction through the supply of products of international quality standards.
Stainless Steel 304 EFW pipes consist mainly of 18% chromium and 8% nickel, which has good corrosion resistance, especially in acidic and chloride environments. Mechanical properties consist of tensile strength 505 MPa, yield strength 215 MPa and elongation 40%. The pipes show good durability, formability, and high-temperature oxidation resistance. The benefits are excellent resistance to corrosion, fabrication ease, and high-stress application strength. Stainless Steel 304 EFW pipes are best suited for food processing, chemical, and pharmaceutical industries because of their better hygiene and non-reactive nature.
| Specification | ASTM A358 / ASME SA358 |
| Specification | A / SA358 CLASS 1, A / SA358 CLASS 2, A / SA358 CLASS 3, A / SA358 CLASS 4, A / SA358 CLASS 5 |
| Grades | 304, 304L, 304H, 309S, 310S, 316, 316L, 316H, 317L, 321, 321H, 347, 347H, 904L ETC. |
| Type | EFW, ELECTRIC FUSION WELDED |
| Outer Diameter Size | Electric Fusion Welded / ERW- 8″ NB To 110″ NB (Nominal Bore Size) |
| Wall Thickness | Schedule 10 To Schedule 160 (3 mm to 100 mm Thickness) |
| Length | 01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size. |
| Ends | Plain Ends / Beveled Ends |
| Delivery Conditions | As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered |
| Coating | Electropolish, Mechanical Polish, Satin Finish, Passivated |
| Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME |
| Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
| Packaging | Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| SS 304 | S30400 | 1.4301 | Z7CN18‐09 | X5CrNi18-10 | SUS 304 | 304S31 | 08Х18Н10 |
| Grade | C | Ni | Si | N | S | Mn | P | Cr | Mo | |
| SS 304 | min. | – | 8.0 | – | – | – | – | – | 18.0 | – |
| max. | 0.08 | 10.5 | 0.75 | 0.10 | 0.030 | 2.0 | 0.045 | 20.0 | ||
| Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| SS 304 | 515 | 40 | 205 | 92 | 201 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Selecting Stainless Steel 304 EFW Pipes from Impex Tube India ensures superior corrosion resistance, superior strength, and longevity. Formulated to cater to a wide range of industrial functions, it provides consistent performance in harsh conditions along with cost-effectiveness through competitive pricing.
Impex Tube India is a prominent supplier and manufacturer of Stainless Steel 304 EFW Pipes in Mumbai, India, and provides an extensive range of high-quality tubes and pipes applicable for different industries. Our excellent service and vast inventory make us a reliable choice for local products.
| NPS Designator | Outside Diameter | Nominal Wall Thickness | ||||||||
| in. | mm | Schedule 5SA | Schedule 10SA | Schedule 40SA | Schedule 80SA | |||||
| in. | mm | in. | mm | in. | mm | in. | mm | |||
| 8 | 8.625 | 219.08 | 0.109 | 2.77 | 0.148 | 3.76 | 0.322 | 8.18 | 0.500 | 12.70 |
| 10 | 10.750 | 273.05 | 0.134 | 3.40 | 0.165 | 4.19 | 0.365 | 9.27 | 0.500B | 12.70B |
| 12 | 12.750 | 323.85 | 0.156 | 3.96 | 0.180 | 4.57 | 0.375B | 9.52B | 0.500B | 12.70B |
| 14 | 14.000 | 355.60 | 0.156 | 3.96 | 0.188B | 4.78B | … | … | … | … |
| 16 | 16.000 | 406.40 | 0.165 | 4.19 | 0.188B | 4.78B | … | … | … | … |
| 18 | 18.000 | 457.20 | 0.165 | 4.19 | 0.188B | 4.78B | … | … | … | … |
| 20 | 20.000 | 508.00 | 0.188 | 4.78 | 0.188B | 4.78B | … | … | … | … |
| 22 | 22.000 | 558.80 | 0.188 | 4.78 | 0.218B | 5.54B | … | … | … | … |
| 24 | 24.000 | 609.60 | 0.218 | 5.54 | 0.250 | 6.35 | … | … | … | … |
| 30 | 30.000 | 762.00 | 0.250 | 6.35 | 0.312 | 7.92 | … | … | … | … |
| Grade | Density (kg/m3) | Specific Heat 0-1000C (J/kg.K) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Electrical Resistivity (n.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| 304 | 8000 | 500 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 720 |
We can provide customized size Stainless Steel 304 EFW Pipes as per your requirement. Our specialized personnel at Impex Tube India has dedicated solutions to all your tube and pipe demands. For more information, contact us at sales@impextubeind.com
Stainless Steel 304 EFW pipes find extensive applications in different industries because they possess excellent mechanical properties and corrosion resistance. They are usually found in the food and beverage sector for equipment like pipelines, tanks, and heat exchangers. Stainless Steel 304 EFW tubes are utilized in chemical processing, pharmaceutical production, and water treatment facilities because of their resistance to corrosion and high temperatures. Besides, they are used in architectural applications, in marine conditions and in the fabrication of pressure vessels, providing reliability and durability in harsh conditions.
