Home > Stainless Steel > Stainless Steel Perforated Tubing
Impex Tube India is a prominent stainless steel tubes and pipes manufacturer and supplier in Mumbai, India, offering expertise in Stainless Steel Perforated Tubing. Focusing on innovation, precision, and longevity, the company provides perforated tubing solutions that cater to the needs of various industries and commerce. Renowned for meeting international standards, Impex Tube India produces products that provide exceptional performance, beauty, and strength. Working across industries such as construction, filtration, and architecture, the organization blends advanced technology and skilled craftsmanship to deliver secure and affordable stainless steel perforated tubing to domestic and international markets.
Stainless Steel Perforated Tubing is generally constructed from stainless steel grades like 304, 316, and 316L, which comprise iron, chromium (10.5% and above), nickel, and in some cases molybdenum. With this composition, there is superb corrosion resistance, strength, and durability. The tubing has evenly spaced holes or slots, which are produced through careful perforation treatments. Mechanically, it still has high tensile strength (up to 750 MPa), stability, and resistance to temperature and pressure changes. Perforations provide better airflow, fluid flow, or filtration efficiency without detracting from overall strength, which makes the tubing perfect for functional and aesthetic uses in harsh applications.
| ASTM | ASTM A249, A269, A270 |
| OD. | 1/8” NB to 24” NB, 1/4” OD to 24” OD sizes stainless steel welded tubes also available |
| Thickness | 0.2mm to 15mm |
| Hole size | 3mm dia on a 6mm pitch |
| Opening diameter | 0.2mm to 100mm |
| Material | SS 304, SS 304L,SS 316,SS 316L, SS201 |
| Finish | BA Finish inside and outside, Perforated finish inside and outside |
| Type | As Welded, EFW, ERW, Seamless, Semi Seamless, Bead Removed |
| Mill Test Certificate | EN10204 3.1 |
| Packing | Sleeved, Ends Capped, Wooden Boxed |
| STAINLESS STEEL Perforated TUBE GRADES | UNS | C | Mn | P | S | Si | Cr | Ni | Mo | Ti | Nb | N |
| TP304 | S30400 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | ||||
| TP304L | S30403 | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | ||||
| TP316 | S3160 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
| TP316L | S31603 | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
| Treatment | Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| º F(º C) | |||||
| TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
| TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| GRADE | UNS NO | DIN/WERKSTOFF |
|---|---|---|
| 304 | S30400 | 1.4301 |
| 304L | S30403 | 1.4306 |
| 316 | S31600 | 1.4436 |
| 316L | S31603 | 1.4404 |
Choosing Stainless Steel Perforated Tubing from Impex Tube India ensures outstanding corrosion resistance, high strength, and durability. Our Tube is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Impex Tube India, one of the largest suppliers of Stainless Steel Perforated Tubing in Mumbai, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
| SIZE OD | NOMINAL WALL THICKNESS | OUTSIDE DIAMETER TOLERANCE | LENGTH TOLERANCE | WALL THICKNESS TOLERANCE | ||||
|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (%) |
| ½ | 12.7 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| ¾ | 19.1 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 1 | 25.4 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 1½ | 38.1 | 0.065 | 1.65 | +/-0.008 | +/-0.20 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 2 | 50.8 | 0.065 | 1.65 | +/-0.008 | +/-0.20 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 2½ | 63.5 | 0.065 | 1.65 | +/-0.010 | +/-0.25 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 3 | 76.2 | 0.065 | 1.65 | +/-0.010 | +/-0.25 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 4 | 101.6 | 0.083 | 2.11 | +/-0.015 | +/-0.38 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 6 | 152.4 | 0.109 | 2.77 | +/-0.030 | +/-0.76 | +1, -0 | +25.4, -0 | +/-10.0% |
Yes, we offer custom sizes for Stainless Steel Perforated Tubing to meet your specific requirements. Our team at Impex Tube India is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@impextubeind.com.
Stainless Steel Perforated Tubing has a broad range of applications across industries demanding ventilation, filtration, and aesthetics. It is applied to decorative panels, screens, and railing infills in interior and architectural designing for style as well as toughness. It provides sound absorption, air flow, and contaminant separation in filtration and exhaust applications. The vehicle industry utilizes it in mufflers and protective covering. It also finds application in food processing, agriculture, and wastewater treatment for its corrosion-resistance and hygiene qualities. Owing to its strength, accurate perforation, and versatility, stainless steel perforated tubing plays a crucial role in applications where functionality and visual appearance are needed.
